Inconel Pipe Fittings Manufacturer and Suppliers

Most Eminent Manufacturer of Inconel Pipe Fittings, Inconel Pipe Fittings, Inconel Alloy Buttweld Pipe Fittings, Inconel Socket Weld Pipe Fittings, Inconel Threaded Forged Fittings, Inconel Socket weld Pipe Fittings Exporter

Inconel Eccentric Reducer Fittings, Inconel Equal Tee Pipe Fittings, Inconel Pipe End Cap Fittings, Inconel Hex Plug Fittings, Inconel Expansion Joint Fittings, Inconel Swage Nipple, 90 Deg Long Radius Inconel Elbow, 45 Deg Short Radius Inconel Elbow Manufacturer

Here at, Vasraj Stainless Steel, we supplying, manufacturing and exporting a wide range of Inconel Pipe Fittings in accordance with national and international quality standards. We supply these High Nickel Pipe Fittings in various types, shapes, dimensions, sizes, and specifications. Pipe Fitting is used to changing the flow direction, increase/decrease bore diameter and attaching measuring equipment in piping systems.

Inconel Pipe Fittings are standard engineering material, which contains nickel, chromium, and iron as main constituents. These nickel, chromium & iron content offer excellent strength and corrosion resistance over a wide range of temperatures. We supply these Inconel Pipe Fittings in diverse types such as Inconel Buttweld Pipe Fittings, Inconel Socket Weld Fittings, Inconel Threaded Forged Pipe Fittings and Instrumentation Pipe Fittings.

Moreover, our warehouse has the largest stock of these Inconel Pipe Fittings in several material grades including Inconel 600 Pipe Fittings, Inconel 601 Pipe Fittings, Inconel 625, Inconel 800 and Inconel 825 Pipe Fittings, etc. These Inconel Pipe Fittings are highly demanded in processing industries, petrochemical, pharmaceuticals, paper & pulp production, and power generation industries.

Please contact us today to buy these Inconel Pipe Fittings at the most affordable prices. We deliver high-quality products to our worldwide customers.

Inconel 600 Pipe Fittings, Inconel UNS N06625 Pipe Fittings, Inconel Alloy UNS N08800 Fittings Stockist, Inconel 825 Buttweld Fittings, Inconel 601 Socket Weld Fittings, Inconel Alloy UNS N06600 Pipe Fittings Manufacturer

Inconel Pipe Fittings - Quick Section Links

Specifications for Inconel Pipe Fittings

These are the Standard specifications of Inconel Pipe Fittings. We also manufacture and export any custom specification as per client’s requirement. For any custom specification Click Here to contact us.
Specifications ASTM B366 / ASME SB366
Size Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″
Standards
ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Thickness 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75
Type Seamless / Welded / Fabricated

Types of Inconel Pipe Fittings

Inconel 45 Degree Elbow Incoloy 45 Degree Elbow
Inconel® Alloy 45 Degree Elbow ASME SB366 Incoloy 45 Degree Elbow
Inconel Pipe Fittings Inconel Buttweld Fitting
Incoloy Pipe Fitting Incoloy Buttweld Fitting
ASTM B366 Inconel Buttweld Fitting Alloy Eccentric Reducer
Inconel Eccentric Reducer Incoloy Eccentric Reducer
Inconel® Alloy Eccentric Reducer ASTM B366 Incoloy Eccentric Reducer
Alloy Concentric Reducer Incoloy Concentric Reducer
Inconel® Alloy Concentric Reducer ANSI B16.9 Inconel Concentric Reducer

Other Grades of Inconel Pipe Fittings

Inconel 600 Buttweld Fittings Inconel 601 Buttweld Fittings
Inconel 625 Buttweld Fittings Inconel 718 Buttweld Fittings
Incoloy 800 / 800H / 800HT Buttweld Fittings Incoloy 825 Buttweld Fittings
Incoloy 925 Buttweld Fittings Incoloy 330/ SS 330/ Ra 330 Buttweld Fittings

Inconel Pipe Fittings Chemical Composition

Inconel 600 Pipe Fittings Chemical Composition
Grade C Mn Si S Cu Fe Ni Cr
Inconel 600 0.15 max 1.00 max 0.50 max 0.015max 0.50 max 6.00 – 10.00 72.00 min 14.00 – 17.00
Inconel 601 Pipe Fittings Chemical Composition
Grade C Mn Si S Cu Fe Ni Cr
Inconel 601 0.15 max 1.00 max 0.50 max 0.015max 1.0 max balance 58.0-63.0 21.0-25.0
Inconel 625 Pipe Fittings Chemical Composition
Grade C Mn Si S Cu Fe Ni Cr
Inconel 625 0.10max 0.50 max 0.50 max 0.015max 5.0 max 58.0 min 20.0 – 23.0
Inconel 718 Pipe Fittings Chemical Composition
Grade C Mn Si Fe S Cr Al Ni
718 min. bal 17.0 0.2 50.0
max. 0.08 0.35 0.35 bal 0.01 21.0 0.8 55.0
Incoloy 800 / 800H / 800HT Pipe Fittings Chemical Composition
Grade C Mn Si S Cu Fe Ni Cr Al Ti
800 0.10 max 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60
800H 0.05 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60
800HT 0.06 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60ᴬ 0.15 – 0.60ᴬ
Incoloy 825 Pipe Fittings Chemical Composition
Grade C Mn Si S Cu Fe Ni Cr Al Ti
825 0.05 max 1.00 max 0.05 max 0.03 max 1.50 – 3.00 22.00 min 38.00 – 46.00 19.50 – 23.50 0.02 max 0.06 – 1.20
Incoloy 925 Pipe Fittings Chemical Composition
Grade C Mn Si S Cu Fe Ni Cr Al Ti
925 0.03 max 1.00 max 0.05 max 0.03 max 1.50 – 3.00 22.00 min 42.00 – 46.00 19.55 – 22.50 0.01-0.05 max
Incoloy 330/ SS 330/ Ra 330 Pipe Fittings Chemical Composition
Grade C Mn Si P S Cr Cu N
330 min. 0.75 17.0 34.0
max. 0.08 2.0 1.50 0.030 20.0 37.0

Inconel Pipe Fittings Mechanical Properties

Inconel 600 Pipe Fittings Mechanical Properties
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Inconel 600 8.47 g/cm3 1413 °C (2580 °F) Psi – 95,000 , MPa – 655 Psi – 45,000 , MPa – 310 40 %
Inconel 601 Pipe Fittings Mechanical Properties
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Inconel 601
8.1 g/cm3 1411 °C (2571 °F) Psi – 80,000 , MPa – 550 Psi – 30,000 , MPa – 205 30 %
Inconel 625 Pipe Fittings Mechanical Properties
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Inconel 625
8.4 g/cm3 1350 °C (2460 °F) Psi – 1,35,000 , MPa – 930 Psi – 75,000 , MPa – 517 42.5 %
Inconel 718 Pipe Fittings Mechanical Properties
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
718 8.14 g/cm3 1400 °C (2550 °F) Psi – 80,000 , MPa – 550 Psi – 32,000 , MPa – 220 30 %
Incoloy 800 / 800H / 800HT Pipe Fittings Mechanical Properties
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
800 / 800H / 800HT 7.94 g/cm3 1385 °C (2525 °F) Psi – 75,000 , MPa – 520 Psi – 30,000 , MPa – 205 30 %
Incoloy 825 Pipe Fittings Mechanical Properties
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
825 8.14 g/cm3 1400 °C (2550 °F) Psi – 80,000 , MPa – 550 Psi – 32,000 , MPa – 220 30 %
Incoloy 925 Pipe Fittings Mechanical Properties
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
925 8.14 g/cm3 1400 °C (2550 °F) Psi – 80,000 , MPa – 550 Psi – 32,000 , MPa – 220 30 %
Incoloy 330/ SS 330/ Ra 330 Pipe Fittings Mechanical Properties
Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
330

Equivalent Grades for Inconel Pipe Fittings

Inconel 600 Pipe Fittings Mechanical Properties
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Inconel 600 2.4816 N06600 NCF 600 NA 13 МНЖМц 28-2,5-1,5 NC15FE11M NiCr15Fe
Inconel 601 Pipe Fittings Mechanical Properties
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Inconel 601
 2.4851 N06601 NCF 601 NA 49 XH60BT NC23FeA NiCr23Fe
Inconel 625 Pipe Fittings Mechanical Properties
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Inconel 625
2.4856 N06625 NCF 625 NA 21 ХН75МБТЮ NC22DNB4M NiCr22Mo9Nb
Inconel 718 Pipe Fittings Mechanical Properties
Grade UNS No Old British Euronorm GOST Japanese JIS
BS En No AFNOR
Inconel 718 N07718 2.4668
Incoloy 800 / 800H / 800HT Pipe Fittings Mechanical Properties
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 800 1.4876 N08800 NCF 800 NA 15 ЭИ670 Z8NC32-21 X10NiCrAlTi32-20 XH32T
Incoloy 800H 1.4958 / 1.4876 N08810 NCF 800H NA 15(H) ЭИ670 Z8NC33-21 X5NiCrAlTi31-20 XH32T
Incoloy 800HT 1.4859 / 1.4876 N08811 NCF 800HT NA 15(HT) ЭИ670 X8NiCrAlTi32-21 XH32T
Incoloy 825 Pipe Fittings Mechanical Properties
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 825 2.4858 N08825 NCF 825 NA 16 ЭП703 NFE30C20DUM NiCr21Mo XH38BT
Incoloy 925 Pipe Fittings Mechanical Properties
STANDARD WERKSTOFF NR. UNS JIS
Incoloy 925 N09925 NCF 925
Incoloy 330/ SS 330/ Ra 330 Pipe Fittings Mechanical Properties
Grade UNS No Old British Euronorm GOST Japanese JIS
BS En No AFNOR
Incoloy 330 N08330 1.4886

Price List of Inconel Pipe Fittings

Vasraj Stainless Steel is one of the most competitive suppliers of  Stainless Steel products from India. Prices for Inconel Pipe Fittings Products are very affordable.

Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Vasraj Stainless Steel maintains a stock of all standard items and can export them at the best Inconel Pipe Fittings.

Inconel Pipe Fittings - Industries & Applications

Our Inconel Pipe Fittings are used in a wide range of applications and various industries. Below are a few of them:

  • Gas Processing Industries
  • Petrochemical Industries
  • Power Generation Industries
  • Food Processing Industries
  • Chemical Industries
  • Oil & Gas Industries
  • Fertilizers Industries
  • Sugar Industries

Stock Availability of Inconel Pipe Fittings

We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for Inconel Pipe Fittings.

Click to send your requirement.

Prominent Countries where we export Inconel Pipe Fittings

Exporting Inconel Pipe Fittings to Singapore, Malaysia, Hongkong, Thailand, Indonesia, Taiwan. Other countires includes Afghanistan, Albania, Andorra, Austria, Bahrain, Bangladesh, Bhutan, Brunei, Belarus, Belgium, Bulgaria, Cambodia, China, Cyprus, Croatia, Czech Republic, Denmark, Estonia, Egypt, Finland, France, Germany, Greece, Georgia, Hungary, Iceland, Ireland, Italy, Iran, Iraq, Israel, Japan, Jordan, Kazakhstan, Kuwait, Kyrgyzstan, Lebanon, Latvia, Latin America, Liechtenstein, Lithuania, Luxembourg, Malta, Moldova, Monaco, Maldives, Mongolia, Myanmar (Burma), Nepal, North Korea, Netherlands, Norway, Oman, Poland, Portugal, Pakistan, Palestine, Philippines, Qatar, Russia, Romania, Russia, San Marino, Serbia and Montenegro, Slovakia, Slovenia, Spain, Sweden, Switzerland, Saudi Arabia, South Korea, South Africa, Sri Lanka, Syria, Tanzania, Tajikistan, Thailand, Turkey, Turkmenistan, Ukraine, United Kingdom, United Arab Emirates (UAE), Uzbekistan, Vietnam, Yemen.

Cities where we export Inconel Pipe Fittings

Exporting Inconel Pipe Fittings to Bangalore, Hyderabad, Ahmedabad, Chennai, Mumbai, Delhi. Other cities includes Suryapet, Jamalpur, Bhiwadi, Ballia, Ambala, Sadar, Udgir, Miryalaguda, Bansberia, India, Maharashtra, Karnataka, Andhra Pradesh, Kerala, Tripura, Benin, Puducherry, Mizoram, Manipur, Tadepalligudem, Betul, Nagapattinam, Bundi, Baraut, Buxar, Muktsar, Kolkata, Surat, Pune, Jaipur, Lucknow, Kanpur, Nagpur, Indore, Thane, Bhopal, Visakhapatnam, Pimpri and Chinchwad, Patna, Vadodara, Ghaziabad, Ludhiana, Agra, Nashik, Faridabad, Meerut, Rajkot, Gujarat, Tamil Nadu, West Bengal, Gujarat, Bihar, Rajasthan, Uttar Pradesh, Punjab, Haryana, Madhya Pradesh, Jharkhand, Chhattisgarh, Assam, Chandigarh, Orissa, Kalyan, Dombivali, Vasai, Coimbatore, Jabalpur, Gwalior, Vijayawada, Jodhpur, Madurai, Bhadreswar, Kasganj, Kalyani, Nagaur, Port, Blair, Datia, Hinganghat, Banswara, Nagda, Raipur, Kota, Guwahati, Solapur, Hubli and Dharwad, Virar, Varanasi, Srinagar, Aurangabad, Dhanbad, Amritsar, Navi Mumbai, Allahabad, Ranchi, Haora, Isa Town, Sitra, Budaiya, Jidhafs, Adliya, Hawalli, As Salimiyah, Malaysia, Al Hilal al Gharbiyah, Al Hilal ash Sharqiyah, Manama, Riffa, Muharraq, Hamad Town, A’ali, Al Hitmi, Al Jasrah, Al Jumaliyah, Al Ka`biyah, Al Khalifat, Al Khor, Al Khawr, Al Khuwayr, Al Mafjar, Mecca, Mongolia, Medina, Muzahmiyya, Riyadh, Jeddah, Hofuf, Ta’if, Sabah as Salim, Al Farwaniyah, Muscat, As Sib al Jadidah, Salalah, Bawshar, Doha, Abu az Zuluf, Abu Thaylah, Ad Dawhah al Jadidah, Al Arish, Al Bida ash Sharqiyah, Al Ghanim, Al Ghuwariyah, Dammam, Khamis Mushait, Buraidah, Khobar, Tabuk, Ha’il, Hafar Al-Batin, Jubail, Al-Kharj, Qatif, Abha, Najran, Yanbu, Al Qunfudhah, Abu Dhabi–AUH, Ajman – AJM, Sharjah – SHJ, Dubai – DXB, Fujairah – FUJ, Ras Al Khaimah – RAK, Umm Al Quwain – UAQ, Cyprus, Egypt, Iran, Iraq, Israel, Jordan, Kuwait, Lebanon, Syria, Turkey, United Arab Emirates, Yemen, Bareilly, Moradabad, Mysore, Noida, Jamshedpur, Malegoan, Gaya Jalgaon, Udaipur, Maheshtala, Tiruppur, Davanagere, Kozhikode, Gurgaon, Aligarh, Jalandhar, Tiruchirappalli, Bhubaneswar, Salem, Mira and Bhayander, Thiruvananthapuram, Bhiwandi, Bhilai, Nagar, Warangal, Cuttack, Firozabad, Kochi, Nellore, Jammu, Sangli, Miraj, Kupwad, Belgaum, Mangalore, Ambattur, Tirunelveli, Saharanpur, Gorakhpur, Guntur, Bikaner, Amravati, Akola, Kurnool, Bhavnagar, Dehradun, Durgapur, Asansol, Nanded, Waghala, Kolapur, Ajmer, Gulbarga, Jamnagar, Ujjain, Loni, Siliguri, Jhansi, Ulhasnagar.
